Datasheet

MukaTech ARM Series

High-efficiency ARM-based architecture optimized for RDP and Cloud VDI.

Front Interface

Rear Connectivity

105mm Compact Design

Zero-Footprint Mounting

Category	Specification	Details
Processor (CPU)	ARM Cortex A53 RK3328	Quad-core 1.5GHz
Graphics	Mali-400MP2	Support up to 1920*1080P (FHD)
Memory & Storage	1GB RAM + 8GB eMMC Flash	High-speed onboard solid state
Networking	Realtek RTL8111F Gigabit	10/100/1000 Mbps Auto-sensing
I/O Interfaces	5x USB Ports, MIC, SPK	1USB 3.0, 4USB 2.0
Power Efficiency	DC 5V/2A	Ultra-low < 10W Consumption
Cooling	Fanless Passive Design	0dB Silent Operation (No moving parts)

Looking for bulk deployment pricing for these specifications?

Request a Quote for this Model

Model Comparison

Choose the right performance tier for your workforce.

Muka-FL800M

Gigabit Zero Client

Form Factor: Ultra-Small Form Factor (USFF)

Power Efficiency: < 13W

Display Support: Dual Mode (VGA + HD)

Full Technical Specifications

Hardware Engine
CPU	Rockchip RK3328 Quad-core 1.5GHz
Memory	1GB DDR3 RAM
Storage	8GB High-Speed Flash
Graphics	Mali-450MP2 GPU
Software & Connectivity
Protocol	RDP (Remote Desktop Protocol)
Server OS Support	Windows 7/8.1/10 & Multipoint Server 2008-2016
Resolution	Up to 1920x1080P (Full HD)
Networking	Gigabit Ethernet (10/100/1000)

I/O Interface Layout

Comprehensive connectivity in a 106mm chassis

Display Output

1x HD (High Definition)
1x VGA (Legacy Support)

Peripherals

1x USB 3.0 (High Speed)
4x USB 2.0 (Keyboard/Mouse)

Audio & Power

1x SPK Out / 1x MIC In
5V 2.5A DC Input

Zero-Footprint Deployment

Every Muka-FL800M is designed to vanish. Using the standard VESA mount, you can attach the unit directly to the back of any monitor, creating an All-In-One experience without the high cost.

Standard 75/100mm VESA

Compatible with 99% of modern business monitors.

Mounting Hardware Included with Every Order

Ready to test the FL800M in your environment?

We provide pilot units for qualifying South African businesses to test protocol performance and power efficiency on-site.

Request a Demo Unit Talk to an Engineer

Muka-FL120 Efficiency King

The FL120 is our most energy-efficient terminal, drawing only 5W. Optimized for RDP 8.1, it provides a stable, flicker-free experience for standard office productivity.

Core Architecture
CPU	Allwinner A20 Dual-core 1.2GHz
RAM / Storage	512MB RAM / 4GB Flash
Power Draw	5 Watts (Ultra-Low)
Protocol	RDP 8.1 (Enhanced Stability)
Physical & OS
Dimensions	145 x 92 x 22 mm (0.17kg)
Legacy Support	XP / 7 / 8 / 10 / Server 2003-2012
Graphics	Mali-400 MP2 (Full HD 1080P)

5W Power RDP 8.1

Choose the FL800M if:

You need Gigabit network speeds.
You run heavy web browsers or local 1080p video.
You need 5 USB ports for specialized peripherals.

Choose the FL120 if:

Maximum electricity saving is the priority (5W).
The task is basic data entry, HR, or school labs.
Budget-friendly mass deployment is required.

Server Sizing Guide

Ensure your host environment is optimized for MukaTech ARM Terminals.

User Count	Recommended CPU	Recommended RAM	Storage Type
1 - 10 Users	Intel Core i5 / Xeon E3 (4+ Cores)	16GB - 32GB	SATA SSD
10 - 25 Users	Intel Core i7 / Xeon Silver (8+ Cores)	32GB - 64GB	NVMe M.2 SSD
25 - 50+ Users	Dual Xeon Gold / EPYC (16+ Cores)	128GB+	Enterprise SAS/NVMe RAID

Note: Estimates based on standard office productivity (Office 365, Web Browsing, Accounting). For video editing or CAD, please consult our engineering team for custom sizing.

Peripheral Compatibility

Our RDP terminals support a wide range of standard office hardware via USB Redirection.

Network Printers

HP, Canon, Epson & Brother

POS Scanners

USB Barcode & QR Readers

I/O Devices

Wireless Keyboards & Mice

Storage

USB Flash Drives (FAT32/NTFS)

Average Power Usage: 8W - 12W per unit
